The 531 brass ball valve with gearbox control, full bore for shut-off of water, heating, sprinkling, air conditioning and irrigation systems.
| Specification | Value |
|---|---|
| DN inches NPS | 3/8'' |
| DN metric | 12/17 |
| Thread standard | ISO 7-1 Rp |
| Stem sealing material | NBR double O-ring |
| Type of coating | Nickel-plated |
| Opening device | Handwheel |
| Application | Industry |
| Shaft/stem matérial | Brass CW614N |
| DN | DN10 - 3/8'' |
| Face to Face (mm) | 60.0 |
| Fluid | Hot / Cold water |
| Body material | Brass CW617N |
| Number of ways | 2 |
| Bore | Full |
| PS (bar) | 50 |
| Connections | BSP FF |
| Seats | PTFE |
| Ball material | Chrome-plated brass CW617N |
| TS max (°C) | 90 |
| TS min (°C) | -10 |
| Warranty period | 2 years |
| Handle material | Nylon |
| Handle type | With reduction gear |
If you have any questions about this product, please feel free to contact us.
| Product Name | Product Number | EVAC Number | Price | Add to Cart |
|---|---|---|---|---|
| BSP FF Brass CW617N Full 3/8'' | 531003 | S1009899 |
€24.61
(excl. btw)
|
add to cart |
| BSP FF Brass CW617N Full 1/2'' | 531004 | S1009900 |
€31.40
(excl. btw)
|
add to cart |
| BSP FF Brass CW617N Full 3/4'' | 531005 | S1009901 |
€33.37
(excl. btw)
|
add to cart |
| BSP FF Brass CW617N Full 1'' | 531006 | S1009902 |
€45.57
(excl. btw)
|
add to cart |
| BSP FF Brass CW617N Full 1''1/4 | 531007 | S1009903 |
€50.44
(excl. btw)
|
add to cart |
| BSP FF Brass CW617N Full 1''1/2 | 531008 | S1009904 |
€90.37
(excl. btw)
|
add to cart |
| BSP FF Brass CW617N Full 2'' | 531009 | S1009905 |
€114.89
(excl. btw)
|
add to cart |
| BSP FF Brass CW617N Full 2''1/2 | 531010 | S1009906 |
€198.46
(excl. btw)
|
add to cart |
